Application
Technical Index
|
Physical Property |
|||||
|
Item |
Unit |
All-800 |
All-1000 |
All-1100 |
|
|
Max Service Temp Limited |
°C |
800 |
1000 |
1100 |
|
|
Density |
kg/m3 |
220 ~ 270 |
220 ~ 270 |
220 ~ 300 |
|
|
Modulus of Ruptures |
Mpa |
≥0.42 |
≥0.55 |
≥0.58 |
|
|
Cold crushing strength (at 5% deformation room temp) |
Mpa |
≥0.6 |
0.7~1.0 |
0.8~1.0 |
|
|
Linear Shrinkage |
% |
≤2 |
≤2 |
≤2 |
|
|
Thermal Conductivity |
|||||
|
200°C |
W/m.k |
0.085 |
0.098 |
0.101 |
|
|
400°C |
0.100 |
0.110 |
0.113 |
||
|
600°C |
0.152 |
0.158 |
0.162 |
||
|
800°C |
0.214 |
0.218 |
0.221 |
||
|
Compression Strength at 10% deformation after 1000C x16hours |
Mpa |
0.4 |
0.5 |
0.58 |
|
|
Porosity |
% |
90.6 |
90.3 |
90 |
|
|
PH Value |
8 ~ 9 |
||||
|
Moisture (by weight) |
3~5% |
||||
|
Color |
White |
||||
|
Surface |
Original / Polished |
||||
|
Chemical Composition |
|||||
|
SiO2 |
45% ~ 49% |
||||
|
CaO2 |
39% ~ 43% |
||||
|
Al2O3 |
0.38% ~ 0.43% |
||||
|
Size available |
|||||
|
Length(mm) |
Width(mm) |
Thickness(mm) |
|||
|
600 |
300 |
25 ~ 100 |
|||
|
1000 |
500 |
25 ~ 100 |
|||
|
1000 |
600 |
25 ~ 100 |
|||
|
1000 |
610 |
25 ~ 100 |
|||
|
Packing: |
Carton box / Pallet |
||||
◆The result is average value not guarantee value, fluctuate within the standard value, for more details about our products properties or technical support, please contact ALLTHERM Technical Department .
